Schlage M490DE-2 Double Electromagnetic Lock, 1500 lbs. Holding Force, Delayed Egress

Schlage Electronics M490DE-2 Double Electromagnetic Lock, 1500 lbs. Holding Force, Delayed Egress

The Schlage Electronics M490DE-2 is a heavy-duty double electromagnetic lock designed for commercial security applications requiring reliable access control and delayed egress functionality. Featuring a powerful 1500 lbs. holding force, this Grade-level electromagnetic locking solution provides strong door security while supporting life safety requirements with delayed egress operation.

Built with a durable aluminum housing and a satin aluminum clear anodized finish (628/US28), the M490DE-2 is designed for long-lasting performance in commercial environments. The lock operates on 12/24 VDC power and includes a door position sensor for enhanced monitoring and access control integration.

The double magnetic lock design provides secure locking for paired doors, making it ideal for entrances, restricted areas, and high-security applications. The unit is UL Listed for UL 10C 3-hour fire rating and UL 294, ensuring dependable performance for commercial installations.

Product Features:

• Double electromagnetic lock with delayed egress functionality

• 1500 lbs. holding force for strong door security

• Designed for commercial applications

• Includes door position sensor switch

• Operates at 12/24 VDC

• Durable aluminum construction

• Satin aluminum clear anodized finish (628/US28)

• UL 10C 3-hour fire rating and UL 294 listed

Technical Specifications:

• Manufacturer: Schlage Electronics

• Model: M490DE-2

• Holding Force: 1500 lbs.

• Operating Voltage: 12/24 VDC

• Current Draw: 1.5A / 760mA @ 12/24 VDC

• Magnet Dimensions: 25-1/16" L x 3" W x 3-1/16" H

• Product Dimensions: 25.06" L x 3.06" W x 3" H

• Material: Aluminum

• Finish: 628/US28 Satin Aluminum Clear Anodized

• Pack Quantity: 1 Each

• Ship Weight: 32 lbs.

The Schlage Electronics M490DE-2 is an excellent choice for facilities needing enhanced security, delayed egress protection, and dependable electromagnetic locking performance.
