BEA 10IXIOST Presence Sensor for Automatic Sliding Doors

$354.00

(No reviews yet) Write a Review

Brand: BEA Incorporated
SKU:: 10IXIOST

$354.00

Description
Show Reviews

BEA / BEA Sensors

10IXIOST — BEA Sensor Packages

Presence Sensor for Automatic Sliding Doors, Intelligent Programming and Troubleshooting via a Menu-Driven LCD, Fully Monitored Internally, Capable of External Monitoring, 360" Cable for Larger/Higher Doors

Description:

BEA’s IXIO-ST is an effective, versatile and easy-to-use presence sensor for automatic sliding doors. It can be used for both clear door openings and side-lite protection.

Precise infrared curtains coupled with visible alignment beams make the IXIO-ST extremely safe and easy to adjust. This state-of-the-art sensor features an on-board LCD screen that streamlines the installation and setup processes.

The IXIO-ST can be adjusted into an ANSI compliant solution and has earned a comprehensive list of credentials and certifications, including FCC and IP54.

Standards compliant Fully monitored internally, capable of external monitoring

Ease of setup Intelligent programming and troubleshooting via a menu-driven LCD

Technology	Active Infrared
Detection Mode	Presence
Spot Size	2” × 2”
Max. Number of Spots	24 per curtain
Max. Number of Curtains	2
Output Max. Contact Voltage Max. Contact Current Hold Time	Electro-mechanical-relay (potential and polarity free) 30 VDC 1 A Microwave: 0.5 – 9 s (user adjustable)	Solid-state-relay (potential and polarity free) 42 VAC / VDC 400 mA Infrared: 0.3 – 1 s
Test Input	N/A	Sensitivity: Low: < 1 V; High: > 10 V (max. 30 V) Response time on test request: typical: < 5 ms
Supply Voltage	12 – 24 VAC ±10%; 12 – 30 VDC ±10% (to be operated from SELV compatible power supplies only)
Power Consumption	< 2.5 W
Mounting Height	6 ½ – 11 ½’
Temperature Range*	-13 – 131 °F 0 – 95% relative humidity, non-condensing
Degree of Protection	IP54
Applicable Directives	R&TTE 1999 / 5 / EC; LVD 2006 / 95 / EC; MD 2006 / 42 / EC; ROHS 2 2011 / 65 / EU
Dimension	10 3⁄5“ (W) × 2 ¼” (H) × 2 ¼” (D)
Cable Length	10’
Norm Conformity	ISO 13849-1:2008 PL «c» CAT. 2 (under the condition that the door control system monitors the sensor at least once per door cycle) IEC 61496-1:2012 ESPE Type 2
