BEA 10MS51W-S Touchless Actuator, Battery-Powered, 900 MHz Transmitter, Single Gang, "Wave To Open", Hand Logo, Stainless Steel Finish

BEA 10MS51W-S Touchless Actuator – Wave to Open, Wireless, Satin Stainless Steel

The BEA 10MS51W-S Touchless Actuator provides a convenient, hygienic, and hands-free solution for activating automatic doors. Designed for commercial applications, this battery-powered actuator uses active infrared sensing to detect a simple wave of the hand, allowing users to open doors without touching a surface.

The wireless 900 MHz transmitter eliminates the need for hardwiring between the actuator and compatible receiver, making installation easier and more flexible. Its single-gang mounting design fits standard single-gang applications, while the satin stainless steel finish provides a clean, professional appearance suitable for a variety of commercial environments.

The actuator features a clear hand logo to indicate the touchless activation area and offers approximately 3 years of battery life, helping reduce maintenance requirements.

Key Features

• Touchless "Wave to Open" activation

• Wireless 900 MHz transmitter

• Battery-powered with approximately 3-year battery life

• Active infrared sensor technology

• Single-gang mounting plate

• Satin stainless steel finish, 630/US32D

• Hand logo for easy activation identification

• Designed for commercial automatic door applications

• Provides a safe and sanitary alternative to traditional push plates

Product Specifications

• Brand: BEA

• Manufacturer Part Number: 10MS51W-S

• SKU: BEA10MS51WS

• Installation: Commercial

• Wireless: Yes

• Mounting: Single Gang

• Sensor Technology: Active Infrared

• Transmitter Frequency: 900 MHz

• Battery Life: Approximately 3 years

• Receivers: 2

• Operating Voltage: 42 VAC/VDC

• Line Draw: < 0.5 mW idle; < 12 mW upon activation

• Finish: Satin Stainless Steel

• Finish Code: 630/US32D

• Width: 1-1/4"

• Height: 4-1/2"

• Length: 2-3/4"

• Unit of Measure: Each

• Pack Quantity: 1

• Shipping Weight: 0.34 lbs.

Ideal for

The BEA 10MS51W-S is ideal for commercial automatic doors in offices, healthcare facilities, retail stores, schools, public buildings, and other locations where touchless access and improved hygiene are important.

BEA Activation Plates offer a convenient and sanitary way to activate automatic doors while providing reliable operation and a professional appearance.
